Edan SD1 Ultrasonic Fetal Doppler from FetalMon Track Your Baby’s Fetal Heart Rate on the Easy-to-Use Display Screen

SD1 without Bluetooth

The economic version, which can satisfy the basic usage for fetal heart rate tracing.

SD1 with Bluetooth

The internal Bluetooth module makes SD1 possible to work with an Android or iOS APP accessing for tracking baby’s development.

The all-in-one compact SD1 Handheld Fetal Doppler is a remarkable member of the Edan ultrasound doppler family. The conventional technology used by the SD1 is unaffected by common limitations found in other dopplers, such as angled probe placement and the depth of the fetal heart. In addition to clinical usage, the SD1 is also a user-friendly home-based device that allows users to apply the doppler anywhere. Users can quickly locate the fetal heart rate signal with this device, and the ultralow level of radiation ensures a safe application.

The SD1 is a modern all-in-one heartbeat doppler that uses a built-in speaker and a digital display for cable-free monitoring. For early trimester detection of FHR, this baby doppler uses pulse wave technology that improves the quality of the sound performance and minimizes interference, producing clear audio from the sounds of your little one. The doppler's auto shut-down feature extends the duration of working use hours from the standard removable batteries.

The heart doppler's mobile design provides users with excellent performance that is portable and suitable for travel. A Bluetooth model is also available for integration with the compatible Android and iOS APP. With the app, users can easily access growth tracking features for your baby and professional care information to assist new users or those using the monitor at home.

Product Name
Edan Fetal Doppler SD1

Product Model
SD1 Standard Version/Bluetooth Version

Fetal Heart Rate Range
50 bpm - 240 bpm

Resolution
1 bpm

Accuracy
±2 bpm

Overall Sensitivity
≥90 dB (at 200 mm away from the probe surface)

Auto Shut-off
2 minutes (no signal or no operation)

Dimensions
Approximately 48 x 39 x 147 mm (±2 mm)

Weight
<180 g (including battery)

Features

· ALL-IN-ONE design

· Built-in speaker

· Digital display of FHR

· Touch panel for easy control

· Built-in Bluetooth (Optional)

· Volume adjustable

· Android or iOS APP access for tracking baby's development

· 3MHz probe detects fetal heartbeat

· Standard AA batteries for easy replacement

· Automatic power-off for battery power saving

· Pulse wave technology
